Electrical Characteristics
| Module | FE72-18X(ND) | ||||
|---|---|---|---|---|---|
| Maximum Power at STC (Pmax) | 580W | 585W | 590W | 595W | 600W |
| Open – Circuit Voltage (Voc) | 51.30V | 51.50V | 51.70V | 51.85V | 52.00V |
| Short – Circuit Current (Isc) | 14.39A | 14.47A | 14.55A | 14.62A | 14.70A |
| Optimum Operating Voltage (Vmp) | 43.10V | 43.30V | 43.50V | 43.55V | 43.70V |
| Optimum Operating Current (Imp) | 13.47A | 13.53A | 13.59A | 13.67A | 13.73A |
| Module efficiency | 22.5% | 22.6% | 22.8% | 23.0% | 23.2% |
| Power Tolerance | 0 ~ +3% | ||||
| Maximum System Voltage | 1500V DC (UL / IEC) | ||||
| Maximum Series Fuse Rating | 25A | ||||
| Operating Temperature | -40°C to +85°C | ||||
NMOT
| Module | FE54-18X(ND) (Bifaciality 80±10%) | ||||
|---|---|---|---|---|---|
| Maximum Power | 327W | 331W | 335W | 339W | 343W |
| Open – Circuit Voltage (Voc) | 36.80V | 36.90V | 37.10V | 37.20V | 37.40V |
| Short – Circuit Current (Isc) | 11.47A | 11.53A | 11.59A | 11.65A | 11.71A |
| Optimum Operating Voltage (Vmp) | 30.70V | 30.90V | 31.10V | 31.30V | 31.50V |
| Optimum Operating Current (Imp) | 10.65A | 10.71A | 10.77A | 10.83A | 10.89A |
| NMOT | 45±2°C | ||||
Mechanical Characteristics
| Item | Details |
|---|---|
| Solar Cells | Monocrystalline 182 × 91.875mm |
| No. of Cells | 108 (6 × 18) |
| Dimensions | 1722 × 1134 × 30mm |
| Weight | 24.0±0.5kg |
| Glass (Front/Back) | High transmission tempered glass; thickness: 2.0mm |
| Frame | Anodized aluminium alloy |
| Junction Box | IP68 |
| Cable | 4mm² (UL / IEC); length: (+)400mm, (–)200mm / customized length |
| Connectors | MC4-EVO2/MC4 Compatible |
| Packaging Configuration | 36pcs/box, 936pcs/40’HQ container |
Temperature Characteristics
| Item | Value |
|---|---|
| Temperature Coefficient of Pmax | -0.29%/°C |
| Temperature Coefficient of Voc | -0.23%/°C |
| Temperature Coefficient of Isc | +0.046%/°C |
